SATO CL4NX User Manual

451
• Do not repeatedly power on/off the printer.
• If you power the main power source off and then on again quickly, the printer may not
be powered on because it is still in the powering off process. In such a case, press the
power button to power on the printer.
• Do not power off the printer during operation, such as when printing or updating. Doing
so could cause a malfunction of the printer.
• Do not disconnect the power cord until the powering off process is completed on the
printer.
• An incorrect power on/off operation may damage the printer settings. In such a case,
the printer settings are reset to their default values. It is always recommended to use
the power button to allow proper shutdown of the printer and ensure changes made to
menu settings are saved appropriately.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
