455
Resolution CL4NX CL6NX
(1dot = 0.042 mm
(0.0017"))
When you decrease the setting value, the print position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the print position moves opposite the feed direction (toward
the end part of the media).
Offset
Set the stop position of the media.
The setting range varies depending on the print resolution of the printer.
The setting range is as follows:
Resolution CL4NX CL6NX
203dpi
(1dot = 0.125 mm
(0.0049"))
-30 to 0 to 30 dots -30 to 0 to 30 dots
305dpi
(1dot = 0.083 mm
(0.0033"))
-45 to 0 to 45 dots -45 to 0 to 45 dots
609dpi
(1dot = 0.042 mm
(0.0017"))
-90 to 0 to 90 dots -
When you decrease the setting value, the stop position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the stop position moves opposite the feed direction (toward
the end part of the media).
Darkness Adjust
Fine tune the print darkness of the test print.
0 is the lightest and 99 is the darkest.
• The value of [Pitch], [Offset] and [Darkness Adjust] set in the [Factory] menu will reflect
to the same item settings in the [Configure List] menu, [Configure QR] menu and
[Paper Sensor] menu.
