457
Pitch
Set the print position in the vertical direction.
The setting range varies depending on the print resolution of the printer.
The setting range is as follows:
Resolution CL4NX CL6NX
203 dpi
(1 dot = 0.125 mm
(0.0049"))
-30 to 0 to 30 dots -30 to 0 to 30 dots
305 dpi
(1 dot = 0.083 mm
(0.0033"))
-45 to 0 to 45 dots -45 to 0 to 45 dots
609 dpi
(1 dot = 0.042 mm
(0.0017"))
-90 to 0 to 90 dots -
When you decrease the setting value, the print position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the print position moves opposite the feed direction (toward
the end part of the media).
Offset
Set the stop position of the media.
The setting range varies depending on the print resolution of the printer.
The setting range is as follows:
Resolution CL4NX CL6NX
203 dpi
(1 dot = 0.125 mm
(0.0049"))
-30 to 0 to 30 dots -30 to 0 to 30 dots
305 dpi
(1 dot = 0.083 mm
(0.0033"))
-45 to 0 to 45 dots -45 to 0 to 45 dots
609 dpi
(1 dot = 0.042 mm
(0.0017"))
-90 to 0 to 90 dots -
When you decrease the setting value, the stop position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the stop position moves opposite the feed direction (toward
the end part of the media).
