SATO CL4NX User Manual

465
• The data files of the receive buffer are created for each type of interface.
• The details of the file created inside "buff/" of the printer are as follows:
BT0001.bin
The contents of the receive buffer for Bluetooth.
LAN0001.bin
The contents of the receive buffer for LAN.
LPT0001.bin
The contents of the receive buffer for IEEE1284.
NFC0001.bin
The contents of the receive buffer for NFC.
PIPE0001.bin
The contents of the receive buffer for pipe.
SCI0001.bin
The contents of the receive buffer for RS-232C.
USB0001.bin
The contents of the receive buffer for USB.
WIFI0001.bin
The contents of the receive buffer for wireless LAN.
• If you perform the [Buffer Dump] again, the existing file will be overwritten.
[Log Files]
The setting items are as follows:
Copy
Copy the log files of the printer to the USB memory.
◦ Available only if you have installed the USB memory.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
