SATO CL4NX User Manual

481
[Settings]
Set the barcode check function.
The setting items are as follows:
Mode
Select the check mode or disable the barcode check function.
Start Position
Adjust the position at which the barcode check starts (position of the barcode checker at which
reading starts).
VOID Print
Set whether to print error marks on the media when a barcode reading error or barcode
comparison error occurs.
Retry Count
Set how many times the printer will try to print and check the same barcode after VOID printing
when a barcode reading error or barcode comparison error occurs.
◦ Appears only if you have selected [Enabled] in the [VOID Print] menu.
Host Notification
Set whether to return the barcode check results to the host from which the print data is sent.
Logs
Manage the barcode check log data saved in the printer.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
