SATO CL4NX User Manual

627
Item Specification
(1) Media feed direction
(2) Cutter cover
(3) Cut position
(4) Print head
(5) Readable area (for the minimum media pitch)
(6) Unreadable area
(7) Minimum media pitch
Cut & Print mode
Do not print a 2D code or serial barcode (90° or 180° orientation in
relation to the media feed direction) within the following area as it
may cause a white void.
◦ CL4NX: 18 to 23 mm (0.70" to 0.90") from the front end of the label
(cut position)
(1) Media feed direction
(2) Cutter cover
(3) Cut position
(4) Print head
(5) Range in which white voids occur
◦ CL6NX: 19 to 25 mm (0.75" to 0.98") from the front end of the label
(cut position)

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
