SATO CL4NX User Manual

718
Error Message 1017 (SBPL Command Error)
When there is an error with the printer, the error message appears on the screen.
Check the cause and countermeasure, and then take appropriate action.
To clear the error:
Press the button (CANCEL) or button.
Cause and Countermeasure
Cause
Incorrect command or parameter in the print data.
For details of the error, check the "Caaa: <bb>: cc" part at the bottom of the screen.
◦ Caaa: position of error occurrence
◦ <bb>: error command name
◦ cc: error content
How to See the Command Error Information
Countermeasure
Check the print data.
If the error is not solved, power on the printer again.
• The command error appears when [Show Error] in [SBPL] under the [Applications]
menu is set to [Enabled].
Show Error
Contact your SATO technical support center if the error cannot be resolved.
Contact Information for When You Are in Trouble

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
