SATO CL4NX User Manual

749
Item CL4NX CL6NX
Linerless mode
30 to 75% RH (Non-condensing)
Storage Humidity 30 to 90% RH (Non-condensing)
Print
Item CL4NX CL6NX
Print Method Direct thermal and thermal transfer
Print Speed
203 dpi
2 to 10 inches/sec (50.8 to 254
mm/sec)
305 dpi
2 to 8 inches/sec (50.8 to 203.2
mm/sec)
609 dpi
2 to 6 inches/sec (50.8 to 152
mm/sec)
Linerless mode
2 to 6 inches/sec (50.8 to 152
mm/sec)
203 dpi
2 to 10 inches/sec (50.8 to 254
mm/sec)
305 dpi
2 to 8 inches/sec (50.8 to 203.2
mm/sec)
Resolution (Head
Density)
• 203 dpi (8 dots/mm)
• 305 dpi (12 dots/mm)
• 609 dpi (24 dots/mm)
• 203 dpi (8 dots/mm)
• 305 dpi (12 dots/mm)
Non-printable Area Pitch direction (Excludes liner)
Top
1.5 mm (0.06")
Bottom
1.5 mm (0.06")
Width direction (Excludes liner)
Left
1.5 mm (0.06")
Right
1.5 mm (0.06")

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
