Item CL4NX CL6NX
Media Length (With
Liner)
• 30 to 400 mm (1.18" to 15.75")
Media Width
• 22 to 128 mm (0.87" to 5.04") • 47 to 177 mm (1.85" to 6.96")
Media Width (With
Liner)
• 25 to 131 mm (0.98" to 5.16") • 50 to 180 mm (1.97" to 7.01")
Diameter of Liner
Winding
Maximum φ120 mm (4.72")
*Above pitch and width are valid for die-cut labels. For media without liner like tags, refer to the
value 'with liner'.
• Linerless
Item CL4NX CL6NX
Media Length 30 to 120 mm (1.18" to 4.72") -
Media Width 60 to 118 mm (2.36" to 4.65") -
• The usable media sizes, the output speed and print quality vary depending on the
media specification, media and ribbon combination, printer settings and outputting
environment. It is recommended to perform a test print with the media and ribbon to be
used in advance.
Roll Diameter (Media Roll)
• Maximum φ220 mm (φ8.66")
• When using a dispenser unit with liner rewinder
Maximum φ220 mm (φ8.66")
Core Diameter (Media Roll)
• φ76 mm (φ3"), φ101 mm (φ4")
• When using a dispenser unit with liner rewinder
φ76 mm (φ3")
• Recommend to use 4" core for thick paper (more than 150 μm (0.0059")), non-
adhesive media and RFID tags/labels (CL4NX only).
Height (Fan-fold Media)
• Maximum 200 mm (7.87")
• When the printer and media are configured to the same height.
