SATO CL608 - Page 161

PN 9001024
Rev. B Jan. 2000
Page 9-9
SECTION 9 – Addendum
SATO CL608 & CL612 SERVICE MANUAL
Serial No. 81199999 and below
9-5 Replacing the Power Supply
Fig. 9-6
REMOVE TOP AND
BOTTOM SCREWS
REMOVE TOP AND
BOTTOM SCREWS
FROM BACK END
OF PRINTER
Figs. 9-5
CL608 & CL612
Serial #8199999 and below
