IPE100 indicator NU-IPE100-IO-USER-E-0212
13
4.1.4 HELP MENU
By pressing at length the HELP key it is possible to access a menu containing the list of keys with the relative function, and
status (locked or unlocked) indication.
The display shows:
- in the upper part: the key, followed by the code of the linked function in the << F.Keys >> step, and a symbol
Indicating whether the key is unlocked ( ) or locked ( ) in the << EN.KEYS >> step.
- in the lower part: the description of the linked function.
Scroll the list with the arrow keys  , press the C key to exit.
4.1.5 INDICATOR CONNECTED TO PC KEYBOARD
It’s possible to connect a PC keyboard (optional), used to emulate the functions of the keys of the indicator.
The keys are managed in the following way:
KEYBOARD KEY OR FUNCTION EMULATE
Esc
-C key.
- If pressed at start-up, it allows entering in the technical SETUP.
In the alphanumeric input, it deletes all entered characters.
 and Canc
-C key.
- If pressed at start-up, it allows entering in the technical SETUP.
In the alphanumeric input, it cancels first the characters which follow the cursor, then the ones which
precede it, one at a time.
Enter

- Fn key.
- Confirms the entered value.
- Enters the displayed step
Numeric and
alphanumeric
keys, SHIFT and
CAPS LOCK
- Quick entry of a numeric and alphanumeric string: through the CAPS/LOCK or SHIFT key it is possible
to switch from the capital letters to the lower case letters, and vice versa, or enter the second character
corresponding to the key (for example ", %, &, /, ? )
Cursor keys
 
- Scroll the parameters
- Increase or decrease the blinking digit while entering a value.
Cursor keys
 
- When entering a value or an alphanumeric string, it scrolls the digits to the right or to the left.
F1, F2….F10
F1,F2….F10 keys.
F11
2ndF key
F12
TARE key.
NOTE: through the remote keyboard, it’s not possible to carry out the functions made by pressing the keys at length.
F1:302  C
CUSTOMER DATABASES
