IPE100 indicator NU-IPE100-IO-USER-E-0212
9
3.2 POWER SUPPLY
- The IPE100 indicator is powered with 12Vdc voltage (8 ÷ 36 Vdc in the IO version), through an internal adapter which
converts the 100 ÷ 240Vac, 50÷60Hz mains voltage, and 6 Vdc, from the built-in battery (fitted depending on the model).
TO POWER the instrument through the 240 Vac mains, or TO RECHARGE the battery, insert the plug and the adapter to
the 240 Vac mains socket.
To connect the indicator to the power mains, the safety regulations must be observed, including the use of a "clean" line
without disturbances or interference caused by other electronic equipment.
The battery inside the indicator, lasts about 25 hours (without the expansion board, with 1-cell platform) and it needs a
recharging time of about 12 hours.
BATTERY FEATURES
Material LEAD
Power 4,5 Ah
Voltage 6 V
THE BATTERY MUST BE SUPPLIED DIRECTLY FROM THE MANUFACTURER.
NOTE: it is advisable to completely recharge it (12 hours) in the first installation of the instrument; we
RECOMMEND disconnecting the battery if the instrument is not going to be used for more than 30 days.
Do not connect other equipment to the same socket as the one that the adapter is in.
Do not step on or crush the power supply cable
3.3 START UP
TO TURN ON the IPE100 press the C key until the display turns on; then release.
The display shows:
- Initially a welcome message (settable in the TECHNICAL SETUP, << LoGo >> StEP, TECHNICAL MANUAL) while the
instrument carries out a series of checking and preheating self tests.
- E-AF03 - XX” name of the installed software, in which XX identifies the software language.
XX.YY is the software version installed.
- “EXECUTION AUTOZERO”
The instrument carries out the "autozero at start-up” function: if a weight is detected within the percentile set in the <<
Auto-0 >> step (TECHNICAL MANUAL.), it is cleared; if the weight is not within this tolerance:
- with a non approved instrument, the display shows the weight after a few instants,
- with an approved instrument, the message “EXECUTION AUTOZERO” appears continuously on the display, until the
weight is within tolerance.
The auto zero function at start-up may be disabled in the SETUP environment (only with non approved instrument); see
SEtuP >> ConFiG >> PArAm. >> Auto-0 (TECHNICAL MANUAL.)
By pressing the 2ndF key for an instant while the version is shown in the display, the indicator will shown in this order:
01.01 in which 01 indicates the instrument type, 01 indicates the metrological software version.
XX.YY.ZZ is the installed software version.
HH is the installed hardware version (08).
LEGAL FOR TRADE or HIGH RESOLUTION if the instrument is APPROVED or UNAPPROVED, respectively.
9.XXXXX is the the g gravity value.
3.4 TURNING OFF THE INSTRUMENT
TO TURN OFF the IPE100 keep the C key pressed until the “- OFF -“ message appears on the LED display and “ ***
POWER OFF *** ” on the LCD display.
