IPE100 indicator NU-IPE100-IO-USER-E-0212
22
7.5 LOCKED / UNLOCKED TARE
Normally, when a tare value has been entered (automatically, manually or from storage) by unloading the scale plate, the
display shows the tare value with a negative sign (LOCKED TARE). One can also choose that the tare value is cancelled
automatically, each time that the scale is unloaded (UNLOCKED TARE):
CONDITIONS FOR AUTOMATIC UNLOCKING:
- In case of SEMI AUTOMATIC TARE, the net weight before the scale unloading may also be 0.
- In case of MANUAL TARE, CALCULATED TARE or FROM DATABASE, the net weight before the scale unloading
must be of at least 2 stable divisions.
By pressing at length the F5 key it is possible to quickly lock/unlock the tare:
DISPLAY MEANING
LoCK LOCKED TARE
unLoCK UNLOCKED TARE
The setting of the tare may be made also in the “TARE LOCKED/UNLOCKED” SEtuP >> tArE t parameter of the
TECHNICAL SETUP, TECHNICAL MANUAL.
7.6 LIMITATION OF THE TARE FUNCTIONS
For specific requirements, it is possible to limit the tare functions with approved instrument; by setting “YES” in the SEtuP
>> d.SALE step of the SETUP environment (TECHNICAL MANUAL.):
- the SEMIAUTOMATIC TARE can not be modified with a manual or calculated tare, or one from database.
- the manual or calculated tare, or one from database must be entered or modified only with UNLOADED scale.
With approved instrument, the SEtuP >> d.SALE step is read only.
7.7 TARE EXECUTION MODE OR DISABLING OF THE TARE
It’s possible to select the tare execution mode, through the setting of the F.ModE >> totAL >> tArE step (TECHNICAL
MANUAL.):
- By setting "diSAbL" one disables all the tare operations;
- By setting "Lock" or “Unlock”, all the tare operations described in section 7.5 are enabled.
7.8 LINKING A PRESET TARE TO A VEHICLE IN THE DATABASE
It is possible to link a tare value to each article of the vehicle database; this tare value will be enabled with each vehicle
selection. Press the C key to cancel the stored tare entering.
See section 11.3 for further details.
8. MULTIPLE RANGE AND MULTI-INTERVAL FUNCTION
The multiple range functioning allows to subdivide the scale capacity in two or three ranges, each which is up to 3000
divisions, improving in this way the first range division in the dual range and the first two ranges in the triple range.
For example it is possible to approve the weighing system with:
- A single range: 6 kg capacity and 2 g division (3000 div.).
- Dual range: 6 /3 kg capacity and 2/1 g division (3000 + 3000 div.).
- Triple range: 15 / 6 / 3 kg capacity and 5/2/1 g division (3000 + 3000 + 3000 div.).
NOTE: For the approval of the weighing system in dual and triple ranges the cell must have better technical features in
comparison to the cell used for the approval in a single range.
This functioning is indicated by the turning on of the indicator which identify the range in which one is working: W1 first
range, W2 second range, W3 third range (if configured); by passing to the W2 range, the second range division is enabled;
by passing to the W3 range, the third range division is enabled, at this point the W1 first scale division is restored only by
passing the gross zero of the scale.
The multi-interval functioning is similar to MULTIPLE RANGE, but with the difference that a range division is enabled as
soon as one enters in its range interval (in other words without passing by the scale zero).
NOTE: The selection of the range number with multiple range and multi-interval functioning is made during the indicator
calibration (TECHNICAL MANUAL.).
