13.2.2 OUTPUT WEIGH
13.2.2.1 SINGLE VEHICLE
(F.ModE >> totAL >> WEi.Mod step set on “nor.WGt”, TECHNICAL MANUAL.)
- Position the vehicle on the scale.
- Select, if requested, the customer / material / vehicle to be linked to the weigh.
- Now it’s possible to proceed in two ways:
1) Directly type in the ID code and press F7.
2) Press F7: one enters the menu of the “open” input weighs:
Select the desired weigh using the arrow keys  .
Confirm with ENTER or press C to exit.
- In both cases, the indicator executes the printout (if configured), and then displays the weight on the scale.
13.2.2.2 VEHICLE WITH TRAILER
(F.ModE >> totAL >> WEi.Mod step set on “SEC.WGt”, TECHNICAL MANUAL.)
- Proceed the same way with the weigh of the single vehicle (see previous paragraph).
- The LCD display will show:
Or, if one has configured TWO SCALES:
At this point one should position the trailer on the scale, wait a few instants for the weight stability.
By pressing ENTER it is possible to:
- CONFIRM THE SAME If in the F.ModE >> totAL >> C.EntEr parameter of the setup one sets PLATFORM
“ConFEr” (CONFIRM SCALE), TECHNICAL MANUAL.
- CHANGE PLATFORM: If in the F.ModE >> totAL >> C.EntEr parameter of the setup one sets “inVErt” (INVERT
SCALE), TECHNICAL MANUAL.
Note: It is in any case possible to change the platform by pressing the 1 key for platform 1 or the 2 key for platform 2.
In the printout, the trailer weight will be shown separately (“TRAILER” item), right below the tractor weight (“OUTPUT” item).
By pressing C the weigh is cancelled and the indicator returns to the weighing mode (“OUTPUT” item).
NOTES ON THE OUTPUT WEIGH:
• If there is a tare, a SINGLE WEIGH is executed.
• By entering an ID code not yet linked to a weigh, the indicator shows on the LCD display “MEMORY IS EMPTY”
and emits a prolonged sound; then it cancels the weigh and returns to weighing.
• By entering the ID code of an already executed weigh, the LCD display will show:
ID: 1
IN: 995kg
SECOND WEIGH?
ENTER=YES C=NO
SECOND WEIGH? C=NO
1=SCL.1 2=SCL.2
W E I G H A L R E A D Y
D O N E , C O N T I N U E ?
