2. MAIN TECHNICAL SPECIFICATIONS
POWER SUPPLY
- 12 Vdc ( 8 ÷ 24 Vdc in the IO versions), with internal 100 ÷ 240 Vac (50÷60 Hz)
/ 12 Vdc adapter.
- 6 Vdc from fitted rechargeable built-in battery.
MAXIMUM POWER 16 VA.
OPERATING TEMPERATURE From -10 to +40 °C.
CONVERTER 24 bit Sigma Delta.
CONVERSION SPEED 200 conv./sec with automatic selection.
RANGE OF INPUT SIGNAL 0,6 mV/V - 3,2 mV/V.
MINIMUM VOLTAGE PER DIVISION
0.3
μ
V (approved instrument); 0.03
μ
V (non-approved instrument).
AUTOMATIC ZERO DETECTION Only in gross mode, programmable at +/- ¼, ½, 1, 2 divisions.
ZERO RANGE Configurable up to +/- 50% of max load capacity.
AUTO ZERO AT START-UP Configurable up to +/- 50% of max load capacity.
LOAD CELL POWER SUPPLY 5Vdc ± 5%, 120mA (max 8 350-Ohm cells).
LOAD CELL CONNECTIONS 6 wires with Remote Sense.
DISPLAY DIVISIONS
10000e, 3 x 3000e for legal for trade weighing, expandable up to 800.000 for
internal use (with minimum signal coming from the 1,6 mV/V cell).
DISPLAYS
- Red, high-luminosity LED indicators, with six digits (h 13 mm).
- Back lit graphic 160x32 dot LCD.
DATABASE/MEMORY
Database of 500 customers (3 descriptions of 25 characters).
Database of 500 materials (2 descriptions of 20 characters).
Database of 500 vehicles (plate of 10 characters, description of 20 characters,
linked tare).
SIGNALS 16 status LEDs. Graphic icons on LCD display.
KEYBOARD
Impermeable polycarbonate keyboard (IP65 protection degree), with membrane
keys with audible and tactile feedback.
PARAMETER SETUP
Calibration and linearity (up to 8 points), fully digital and programmable from the
keyboard or from PC with Scaletools
CLOCK/DATE Fitted, with buffer RAM.
SERIAL OUTPUTS
- 2 input/output RS232 ports on terminal board/ amp connector.
- 1 input/output RS485 port on terminal board or RS232 on amp connector.
INPUTS AND OUTPUTS
- Management of PC keyboard
- 2 optoisolated inputs (optoisolated photo couplers), 12Vdc – 24Vdc, 20mA max
- 4 outputs (optoisolated photomosfets), 48Vac / 0.15A, 60Vdc / 0.15A, 10 Ω
max.
