Schaerer Ambiente 2

Chapter 4 Fault diagnosis
110 SMSO-2-02.04- 15.07.03
Piston motor malfunction
System / component Possible cause Remedy
Mechanical faults
 Piston motor defective  replace (see “Maintenance, brewing unit
piston motor”)
Piston motor  Piston motor fixing loose  Install the piston motor correctly (see
Maintenance, brewing unit piston motor)
 “Piston motor timeout”  see “Display messages”
Electrical faults
Power PCB
 Defect in cabling or in piston motor
 Direction of rotation is incorrect: flat plug
on motor transposed
 carry out a check (the plugs have differ-
ent dimensions!) (see “control system
diagram, piston motor”)
Position switch  Micro switch for initial setting defective
(message on display “motor current”)
 Check the function and setting of the
position switch (see Maintenance, re-
place/set micro switch” and “control sys-
tem diagram, limit switch for brewing unit
initial setting)
Programming
 Compaction current (compaction pres-
sure) programmed too high
 Correct the programming (see pro-
gramming instructions)
