Block D: Calibration Results
D 01 Nominal belt load
No input possible Preconfigured value: *111.11 kg/m
Calculated from the nominal data B 02 and B 05.
Reference for limit values and zeroing program.
D 02 Range correction
Range: 0.5000...2.0000 Preconfigured value: 1.0000
The parameter proportionally influences the belt-load measurement q.
q(corrected) = q(measured) * D 02
D 03 Total tare
No input required Preconfigured value: 0.00 kg/m
Tare program result.
Caution!
When entering the parameters D 02 and D 03 by hand, D 02 must be entered first.
D 06 Belt circuit number
No input required Preconfigured value: 1,000,000 I/B
The result of the calibration impulse/belt circuit determines the setup program run cycle.
Divided by parameter B 04 (vs characteristic value), this gives the belt length in m.
