Block F: Limit values
If the belt load falls below its MIN value or goes above its MAX value, a corresponding event
message occurs (L2 or H2).
Monitoring commences 10 seconds after the scales has been started.
F 05 Q-MIN value
Range: -10...200.0 % Q Preconfigured value: 20.0 % Q
Reference: Nominal belt load D 01
F 06 Event class Q_MIN L2
The event class is fixed at WARNING 2
F 07 Q-MAX Value
Range: -10...200.0 % Q Preconfigured value: 120.0 % Q
Reference: Nominal belt load D 01
F 08 Event class Q-MAX H2
The event class is fixed at WARNING 2
INTECONT® Satus Operating Manual BV-H2346GB / 0833 45
© Schenck Process
