Block L : Fieldbus
L 01 Protocol type
Range: NO
MODBUS
PROFIBUS DP
DEVICE NET
MODBUS/TCP
ETHERNET/IP
Preconfigured value: NO
Potential types of protocols. An optional interface card is required for the PROFIBUS DP
and DEVICE NET protocols.
PROFIBUS - VPB8020
DEVICENET - VCB8020
ETHERNET/IP over software one de-energizes.
The software can be activated with the Set Option function (on the unit: under
programming). Only Schenck Process can ascertain the activation code.
Parameters L02 - L14 are dependent on the protocol type. The dependencies are listed in
the following table.
BLOCK L Preconfigured
value
MODBUS PROFIBUS DP DEVICE NET MODBUS/TCP ETHERNET/IP
L 01 Protocol type NO x x x x x
L 02 Timeout Host 5 s x x x x x
L 03 Host communication IG (S 09) x x x x x
L 04 Word sequence I:std/L:std x x x x
L 05 Byte Sequence High - Low x x
L 06 Configuration FIXED x x x
L 07 Address 1 x
L 08 Resolution 4096 x
L 09 Baud rate 9600 x
L 10 Data format 8-E-1 x
L 11 Physics RS 485 2-wire x
L 12 Address 16 x
L 13 FLOAT format IEEE x
L 14 Address 63 x
L 15 Baud rate 125K x
Table of active parameters dependent on the protocol type.
L 02 TIMEOUT Host
Range: 1...600s Preconfigured value: 5s
If the TIMEOUT value is greater than zero, a telegram from the host system will be
anticipated within the preset time.
INTECONT® Satus Operating Manual BV-H2346GB / 0833 49
© Schenck Process
