L 03 Communication host S9
Range: IGNORE
W1 (Warning 1)
W2 (Warning 2)
A (Alarm)
Preconfigured value: IGNORE
If no telegram is received within the allotted time set in parameter L02, the event telegram
‘S9 Communication Host’ occurs.
L 04 Word sequence
Range: I:std/L:std
I:swp/L:std
I:std/L:swp
I:swp/L:swp
Preconfigured value: I:std/L:std
The parameter determines the word sequence within a double word.
“I” stands for IEEE-754 values (floating point values)
“L” stands for 4-Byte integer values
“std” does not reverse the word order, “swp” swaps them.
L 05 Byte sequence
Range: Low-High
High-Low
Preconfigured value: High-Low
Determines the byte sequence in a data word.
L 06 Configuration
The process map can be set to FIXED and VARIABLE.
The VARIABLE setting is only to be used in conjunction with the CFC or STEP7 modules!
Further details on this mode of operation can be found in the corresponding module
documentation.
L 07 ADDRESS
Range: 1...254 Preconfigured value: 1
Slave address for Modbus protocol.
L 08 Resolution
Range: 1...32767 Preconfigured value: 4096
Resolving the data in the Modbus protocol nominal value (integer format).
50 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
