Block O: Events
O 01 Mains failure E1
The event class is fixed at WARNING 1
O 02 Memory error S1
The event class is fixed at ALARM
The scales is inoperable.
O 03 Tachometer input C2
The event class is fixed at WARNING 1.
The input frequency exceeds 3,000Hz.
O 04 Tachometer Namur Error E2
The event class is fixed at ALARM
Short circuit or break in the cable.
The internal speed value is set to 0 in the case of a Namur error.
The frequency display (service value) is still active.
O 06 LC Input C1
The event class is fixed at ALARM
1. The load cell cable is not connected or is improperly connected.
2. The measuring amplifier’s analog-digital converter is in saturation (see service value
LC_raw).
The error was present for at least 3s.
O 08 LC Input > MAX H4
The event class is fixed at WARNING 1
The load cell load is greater than 110% of the sum of the load cell nominal loads (C 04).
End of measurement range: approx. 115% with Schenck load cells.
O 09 LC Input < MIN L4
The event class is fixed at WARNING 1
The load cell load is less than 3% of the sum of the load cell nominal loads.
52 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
