Schiller PHYSIOGARD Touch 7 - NIBP - Non-Invasive Blood Pressure; IBP - Invasive Blood Pressure; Temperature

Page 141
Technical Data 12
User guide Technical data - monitoring 12.4
Art. no.: 0-48-0227 Rev.: g
DEFIGARD/PHYSIOGARD Touch 7
12.4.3 NIBP - non-invasive blood pressure
12.4.4 IBP - invasive blood pressure
12.4.5 Temperature
Measurement Automatic or manual
Measuring method Oscillometric
Connection Type CF
Measurement range
Adults(Child
Neonate
• Sys 30...255 mmHg, dia 15...220 mmHg
• Sys 30...135 mmHg, dia 15...110 mmHg
Accuracy ± 3mmHg and ± 2 beats/min
Measuring range -150...400 mmHg
Accuracy 1 mmHg or ± 1% (whichever is greater)
Sampling rate 500 Hz
Amplifier Type CF, defibrillation-protected >5 kV
Zeroing
Manual
Measuring method Direct
Sensor YSI 401, rectal, oesophageal, skin
Amplifier Type CF, defibrillation-protected >5 kV
Sampling rate 2Hz
Measurement interval 1x per second
Measuring range 15 °C to 45 °C
Resolution 0.1 °C
Accuracy ± 0.1 °C from 25 to 45 °C
