Schiller PHYSIOGARD Touch 7 - Back Panel; Leds

2 Components and Operation
2.2 Operating Elements
Page 24
Art. no.: 0-48-0227 Rev.: g
DEFIGARD/PHYSIOGARD Touch 7
2.2.3 Back Panel
Fig. 2.2 Control elements at the device´s back
2.2.4 LEDs
The LEDs give the following information:
Dovetail fixing
joint
Replaceable power battery
DC input from Docking
station
Safety primary cell
compartment for backup
during battery change
(1) Flashes while the battery is being recharged
(2) Unit connected to the external power supply.
Fig. 2.3 LEDs
1 2
