Technical Data 12
User guide Device Configuration 12.6
Art. no.: 0-48-0227 Rev.: g
DEFIGARD/PHYSIOGARD Touch 7
12.6.8 NIBP
12.6.9 SpO2
12.6.10 Temp
12.6.11 EtCO2
Parameter Values Description
Deflation rate • 3, 4, 5, 6, 7, 8, 9 mmHg/s Sets the cuff deflation rate
NIBP unit
•mmHg*
•kpa
Sets the unit in which the NIBP values will be displayed and stored
Automatic cycles at
start
• False*
•True
Automatic NIBP measurement cycle starts once a first measurement is
initiated manually
Initial pressure for
adults
• 90, 120, 150, 180*, 210,
240, 270mmHg
Sets the initial cuff pressure for measurement in adult mode
Initial pressure for
children
• 90, 120, 150*, 180, 210,
240, 270mmHg
Sets the initial cuff pressure for measurement in child mode
Initial pressure for
neonate
• 50*, 70, 90 110,130,
150mmHg
Sets the initial cuff pressure for measurement in neonate mode
Parameter Values Description
SpO2 average • 4, 6, 8, 10,12*,14, 16sec
Sets the integration time for the calculation of the displayed average
value.
SpO2 sensitivity
•Normal*
• Automatic Probe Off De-
tection
Sets the measurement sensitivity.
Adaptive Probe Off Detection is optimised for the detection of Sensor
has come off, regardless of the signal quality.
SpO2 sound level
• Off
• Low
•Medium*
• High
Sets the audio level of the pulse sound
Parameter Values Description
Temperature unit
• Celcius*
• Fahrenheit
Sets the unit in which the temperature value will be displayed and
stored
Parameter Values Description
Respiration curve
amplitude
• 50*, 75, 100mmHg Sets the respiration curve amplitude to be displayed by default
EtCO2 unit
•vol%
•mmHg*
Sets the unit in which the EtCO2 value will be displayed and stored
