12 Technical Data
12.6 Device Configuration
Page 150
Art. no.: 0-48-0227 Rev.: g
DEFIGARD/PHYSIOGARD Touch 7
12.6.5 AED
12.6.6 ECG
12.6.7 IBP
Parameter Values Description
Display curve in
AED
• False
•True*
If enabled, ECG lead Defi is displayed in AED mode
AED voice level
• High
• Medium*
•Low
Metronome default behaviour in adult mode
This behaviour can be changed during intervention on the device
Metronome
behaviour adult
• 30:2*
•15:2
• Continuous Off
Metronome default behaviour in adult mode
This behaviour can be changed during intervention on the device
Metronome
behaviour child
•30:2
• 15:2*
• Continuous Off
Metronome default behaviour in child mode
This behaviour can be changed during intervention on the device
Metronome rate
• 100cpm*
•110cpm
• 120cpm
Sets the frequency of the metronome
Metronome audio
level
• High
• Medium*
•Low
Sets the audio level of the metronome
CPR depth unit
•cm*
•inch
Sets the unit in which the chest compression depth value will be
displayed
CPR cycle duration
•1min
•2min*
•3min
Sets the duration of the CPR cycle
Parameter Values Description
ECG curve
amplitude
• 0.25mv
•0.5mv
• 1mv*
•2mv
• auto
Sets the default ECG curve amplitude, If Auto is selected, the
displayed amplitude will be automatically adapted depending on the
signal amplitude
ECG 16,7 Hz filter
• False*
•True
Not used at the moment, has no impact on the unit
QRS sound level
•Off
• Low*
• Medium
•High
Sets the audio level of the QRS sound issued by the ECG
Parameter Values Description
IBP curve amplitude • 30, 60, 100, 300mmHg Sets the default IBP curve amplitude
