4.3.1 Table of wide/narrow threshold setting
The range values in brackets () are the default values activated when pressing “De-
fault” in the alarm setting menu see Fig. 4.2, page 40. The values before the bracket
“ECG 0-350 (50-150) bpm” are the low/high system limits.
HR [bpm] Pat. value Wide limits Narrow Limits
Range: Low High Low High
ECG 0-350 (50-150) bpm
<60 -20 +35 -10 +25
Pleth 25-240 (50-150) bpm 60-79 -25 +40 -20 +30
80-104 -30 +40 -30 +30
>=105 -35 +45 -25 +25
Allowed values [30-150] [100-240] [30-150] [100-240]
RR [rpm] Pat. value Wide limits Narrow Limits
Range: 0-60 (5-30) resp/min Low High Low High
<15 -8 +8 -4 +4
>=15 -15 +15 -8 +8
Allowed values [5-15] [10-60] [5-15] [10-60]
SpO2 [%] Pat. value Wide limits Narrow Limits
Range: 50-100 (85-100) % Low High Low High
>=90 -5 +3 -5 +3
<90-5+3-5+3
Allowed values [85-100] [90-100] [85-100] [90-100]
SpCO/SpMet [%] Pat. value Wide limits Narrow Limits
Range: Low High Low High
SpCO 0-40 (0-10) %
- 0% 10% 0% 10%
SpMet 0-15%
- 0%3%0%3%
Temperature [°C] Pat. value Wide limits Narrow Limits
Range: 0-46 (35-39) °C Low High Low High
- -3 +3 -1 +1
Allowed value - [31-41] [31-41] [31-41] [31-41]
EtCo2 [mmHg]/ [%] Pat. value Wide limits Narrow Limits
Range: 5-70 mmHg/0.7-9.2 %
(15-50 mmHg/2-6.6 %)
Low High Low High
<40/5.3 -10/1.3 +15/+2.0 -10/-1.3 +15/+2.0
>=40/5.3 -10/1.3 +15/+2.0 +15/+2.0 +15/+2.0
Allowed values [mmHg]/ [%]
[5-60] /
[0.7-7.9]
[20-70] /
[2.7-9.2]
[5-60] /
[0.7-7.9]
[20-70] /
[2.7-9.2]
