Defibrillation 5
User guide CPR Guide 5.6
Art. no.: 0-48-0227 Rev.: g
DEFIGARD/PHYSIOGARD Touch 7
5.6.2 FreeCPR
• The FreeCPR measures the compression rate based on the impedance
measurement by the defibrillation electrodes.
5.6.3 Metronome settings
1. Switch on the device and select manual or AED defibrillation.
2. Apply the defibrillation electrodes.
3. Open the CPR menu and activate the CPR guide.
4. The displayed measurements on the right side of the screen inform you about the
CPR quality and frequency.
1. Open the CPR menu.
2. Activate the metronome.
3. The following settings are available:
– 30:2
– 15:2
– Continuous
CPR
CPR
METRONOME
CPR GUIDE
OFF
ON
CPR
CPR
METRONOME
CPR GUIDE
ON
OFF
Continuous
