4 Monitoring
4.7 NIBP monitoring
Page 58
Art. no.: 0-48-0227 Rev.: g
DEFIGARD/PHYSIOGARD Touch 7
4.7.2 NIBP Menu
4.7.3 NIBP Information and Error Messages
MENU Parameter Description Value
NIBP Automatic cycles Cycle time setting
Automatic cycle of 2/3/5/10/30
minutes
Manual
The measurement is manually initiated by
pressing the soft key.
soft key = Start
NIBP Alarm Code Cause Remedy
Module inoperative
T.NIBP01
T.NIBP02
T.NIBP03
T.NIBP04
T.NIBP05
T.NIBP06
T.NIBP07
• NIBP module failed
Replace device
Unable to inflate cuff T.NIBP08
• No pressure can be measured
• The device is defective
Check cuff and connection.
Replace device
Invalid measurement
T.NIBP09
T.NIBP10
T.NIBP11
• Pressure/pulse below/above
limits
Check cuff and connection for leaks
Unable to measure T.NIBP12
• No signal/pulse detected at 50
mmHg
Check patient, cuff and hose
Cuff not present T.NIBP13
• Pressure in the cuff remains too
low < 10 mmHg during 10 s
Check cuff and connection for leaks
Wrong cuff T.NIBP14
• Pressure too high because
- Too small cuff applied
- Tube buckled
Check cuff and connection.
Artefacts detected
T.NIBP15
T.NIBP16
• Measurement disturbed by ex-
ternal influences
The patient must not move during meas-
urement
Measurement timeout T.NIBP17
• Measurement time exceeded
with no results
Check cuff and connection.
Make sure that the cuff is well applied
Inflate timeout
T.NIBP18
T.NIBP19
• Pumping running time exceed-
ed
Check cuff and connection for leaks.
Pressure out of range T.NIBP20
• Pressure below/above accept-
able range
Check patient, cuff and hose
No pulse I.NIBP01
• No pulse detected
Make sure that the cuff is well applied
Check patient, cuff and hose
