Schiller PHYSIOGARD Touch 7 - Spo 2 Error and Information Messages

Page 53
Monitoring 4
User guide SpO
2
-
,
SpCO
,
SpMet monitoring (Option) 4.6
Art. no.: 0-48-0227 Rev.: g
DEFIGARD/PHYSIOGARD Touch 7
4.6.4 SpO
2
error and information messages
Alarm (measurement field) Code Cause Remedy
SpO2: Low Perfusion Index
The same accounts for:
Low SpCO perfusion
Low SpMet perfusion
I.SP214
I.SP206
I.SP209
• Weak pulse
• Sensor not properly applied
 Check the patient
 Check the sensor and reapply. If
this message is displayed repeat-
edly, the oxygen saturation needs
to be verified by means of another
method.
SpO2: Low SpO2 confidence
The same accounts for:
Low HR (pleth) Confidence
Low SpCO confidence
Low SpMet confidence
I.SP203
I.SP211
I.SP205
I.SP208
• Low pulse signal quality, measurements
are based on a poor signal quality. The
pulse tone, if activated, is low.
 Check the patient
 Check the sensor and reapply or
replace sensor
 If this message is displayed re-
peatedly, the oxygen saturation
needs to be verified by means of
another method
Invalid functional SpO2
The same accounts for:
Invalid HR (pleth)
Invalid SpCO
Invalid SpMet
I.SP204
I.SP212
I.SP207
I.SP210
• Value is not plausible
• SpCO readings may not be provided if
there are low arterial saturation levels or
elevated methaemoglobin levels.
 Check the patient
 Check the sensor and reapply
Pulse Search
T.SP230
• Device is searching for the pulse
 Make sure that the sensor is well
connected to the patient
Sensor Off patient
T.SP229
• Sensor not connected to the patient or
off
 Check the contact between the
sensor and the patient
Check sensor
I.SP231
•SpO
2
sensor failed or disconnected
 Check sensor, compatibility
 Replace the sensor
Board inoperative
T.SP201
T.SP202
T.SP203
T.SP204
T.SP205
T.SP206
T.SP207
T.SP208
T.SP209
T.SP210
& T.SP232
• No SpO2 module installed
 Module not installed or defective
Interference detected T.SP226
• Interferences detected
 Check the sensor on the patient,
check the cable connector, elimi-
nate sources of interferences, e.g.
high frequency devices or strong
light sources.
 Check Line frequency setting 50 or
60 Hz
Check cable
T.SP211
T.SP212
T.SP213
T.SP214
T.SP215
• No cable connected
• Cable life expired
• Incompatible cable
• Unrecognised cable
• Defective cable
 Check/replace cable
