COLORED HOUSING

Standard the housing color of the Schleifenbauer PDUs is black. It is also possible to anodizing the housing in 5 other
colors.

01. black
02. green 
03. orange
04. blue
05. red
06. Yellow

Not shown but available is “natural”

Note:  actual colors may vary!
MEASUREMENTS
Measurements of the input and the outlet level can be found below:

Measurement
Unit
Remark
Energy
(kWh)
total & subtotal
Voltage
(V)
with voltage dip registration
Current
(A)
with peak value registration and drop detection.
Power factor
(%)

Apparent power
(VA)

Real power
(W)

Temperature
(°C)
with optional sensor
Relative humidity
(%)
with optional sensor
NO/NC contact
0-2
devices equipped with a USB-port can operate two NO/NC contacts
(see chapter “How to connect a NO/NC contact)

 


