B.31
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
Special Translation Rules
?CG 0x0003 7010
?CGT 0x1003 7110
1AB 0x001C 1003
1ABC 0x001E 1001
1ABCT 0x101E 1101
1ABG 0x001D 1002
1ABGT 0x101D 1102
1ABT 0x101C 1103
1AG 0x0019 1004
1AGT 0x1019 1104
1BC 0x0016 1006
1BCG 0x0017 1005
1BCGT 0x1017 1105
1BCT 0x1016 1106
1BG 0x0015 1007
1BGT 0x1015 1107
1CA 0x001A 1009
1CAG 0x001B 1008
1CAGT 0x101B 1108
1CAT 0x101A 1109
1CG 0x0013 1010
1CGT 0x1013 1110
1OUT 0x8000 88
1OUT X 0x8000 9035
1OUT Y 0x8000 9036
25T1 0x8000 34
25T2 0x8000 35
27B 0x8000 30
27L 0x8000 31
2AB 0x002C 2003
2ABC 0x002E 2001
2ABCT 0x102E 2101
2ABG 0x002D 2002
2ABGT 0x102D 2102
2ABT 0x102C 2103
2AG 0x0029 2004
2AGT 0x1029 2104
2BC 0x0026 2006
2BCG 0x0027 2005
2BCGT 0x1027 2105
2BCT 0x1026 2106
Tabl e B. 20 Eve nt Typ e s (Sheet 2 of 8)
Event Code for Rule #32 Code for Rule #33
