UCA2 GOMSFE Models
Special Translation Rules
2BG 0x0025 2007
2BGT 0x1025 2107
2CA 0x002A 2009
2CAG 0x002B 2008
2CAGT 0x102B 2108
2CAT 0x102A 2109
2CG 0x0023 2010
2CGT 0x1023 2110
2OUT 0x8000 89
2OUT X 0x8000 9037
2OUT Y 0x8000 9038
3AB 0x004C 3003
3ABC 0x004E 3001
3ABCT 0x104E 3101
3ABG 0x004D 3002
3ABGT 0x104D 3102
3ABT 0x104C 3103
3AG 0x0049 3004
3AGT 0x1049 3104
3BC 0x0046 3006
3BCG 0x0047 3005
3BCGT 0x1047 3105
3BCT 0x1046 3106
3BG 0x0045 3007
3BGT 0x1045 3107
3CA 0x004A 3009
3CAG 0x004B 3008
3CAGT 0x104B 3108
3CAT 0x104A 3109
3CG 0x0043 3010
3CGT 0x1043 3110
3PC1 0x8000 40
3PC2 0x8000 41
3PRI 0x8000 51
4AB 0x008C 4003
4ABC 0x008E 4001
4ABCT 0x108E 4101
4ABG 0x008D 4002
4ABGT 0x108D 4102
4ABT 0x108C 4103
4AG 0x0089 4004
Tabl e B. 20 Eve nt Typ e s (Sheet 3 of 8)
Event Code for Rule #32 Code for Rule #33
