UCA2 GOMSFE Models
Special Translation Rules
BFI Y 0x8000 9024
BG 0x0005 7
BGT 0x1005 107
C 0x0002 57
CA 0x000A 9
CAG 0x000B 8
CAGT 0x100B 108
CAT 0x100A 109
CG 0x0003 10
CGT 0x1003 110
CLOSE 0x8000 28
CLOSE X 0x8000 9007
CLOSE Y 0x8000 9008
CLS1 0x8000 36
CLS2 0x8000 37
CYCL 0x8000 43
D 0x8000 58
DT 0x8000 11
E 0x8000 59
ER 0x2000 12
ER1 0x2000 90
ER2 0x2000 91
ET 0x8000 13
ET1 0x8000 71
ET2 0x8000 72
EXT 0x8000 18
EXT X 0x8000 9029
EXT Y 0x8000 9030
EXTC 0x8000 17
FAULT 0x8000 75
FAULT X 0x8000 9003
FAULT Y 0x8000 9004
G 0x0001 62
H 0x8000 63
HAB 0x000C 6003
HABC 0x000E 6001
HABCT 0x100E 6101
HABG 0x000D 6002
HABGT 0x100D 6102
HABT 0x100C 6103
HAG 0x0009 6004
Tabl e B. 20 Eve nt Typ e s (Sheet 6 of 8)
Event Code for Rule #32 Code for Rule #33
