UCA2 GOMSFE Models
Special Translation Rules
HAGT 0x1009 6104
HBC 0x0006 6006
HBCG 0x0007 6005
HBCGT 0x1007 6105
HBCT 0x1007 6106
HBG 0x0005 6007
HBGT 0x1005 6107
HCA 0x000A 6009
HCAG 0x000B 6008
HCAGT 0x100B 6108
HCAT 0x100A 6109
HCG 0x0003 6010
HCGT 0x1003 6110
I 0x8000 64
INT 0x8000 29
LJAM 0x8000 81
LJAM X 0x8000 9019
LJAM Y 0x8000 9020
LLOSS 0x8000 82
LLOSS X 0x8000 9021
LLOSS Y 0x8000 9022
LOCK 0x8000 44
LTCH 0x8000 54
MER 0x8000 70
OPEN 0x8000 14
OPEN X 0x8000 9005
OPEN Y 0x8000 9006
OTT 0x8000 45
PULSE 0x8000 92
RETRIP 0x8000 84
RETRIP X 0x8000 9025
RETRIP Y 0x8000 9026
RSET 0x8000 42
RUN 0x8000 76
RUN X 0x8000 9009
RUN Y 0x8000 9010
SPC1 0x8000 38
SPC2 0x8000 39
SPRI 0x8000 74
ST 0x8000 60
START 0x8000 77
Tabl e B. 20 Eve nt Typ e s (Sheet 7 of 8)
Event Code for Rule #32 Code for Rule #33
