UCA2 GOMSFE Models
Special Translation Rules
START X 0x8000 9011
START Y 0x8000 9012
STL 0x8000 80
STL X 0x8000 9017
STL Y 0x8000 9018
STOP 0x8000 78
STOP X 0x8000 9013
STOP Y 0x8000 9014
THERM 0x8000 79
THERM X 0x8000 9015
THERM Y 0x8000 9016
TIMER1 0x8000 86
TIMER1 X 0x8000 9031
TIMER1 Y 0x8000 9032
TIMER2 0x8000 87
TIMER2 X 0x8000 9033
TIMER2 Y 0x8000 9034
TR 0x8000 16
TRI 0x8000 73
TRIG 0x8000 15
TRIG X 0x8000 9001
TRIG Y 0x8000 9002
TRIP 0x8000 19
TRIP3 0x8000 27
TRIPA 0x8000 21
TRIPAB 0x8000 24
TRIPB 0x8000 22
TRIPBC 0x8000 25
TRIPC 0x8000 23
TRIPCA 0x8000 26
TRP1 0x8000 93
TRP2 0x8000 94
TRP3 0x8000 95
W 0x8000 66
X 0x8000 67
Y 0x8000 68
ZT 0x8000 69
other 0x8000 9999
Tabl e B. 20 Eve nt Typ e s (Sheet 8 of 8)
Event Code for Rule #32 Code for Rule #33
