OPERATING INSTRUCTIONS
Trimming the VTS Using the VTS
Button
Nine trim positions are available.
With the watercraft operating in for-
ward thrust, proceed as follows.
NOTE: Pressing the VTS trim button
without the engine in forward thrust
will only change the indication. The
nozzle will move to the selected VTS
trim position when forward thrust is
engaged.
1. Press the VTS UP button once to
trimthebowofthewatercraftupto
the next up trim position.
2. Press the VTS DOWN button once
to trim the bow of the watercraft
down to the next down trim posi-
tion.
sdd2009-001-019_c
TYPICAL - VTS CONTROL BUTTON
1. Bow up
2. Bow down
sdd2009-001-042_a
INFORMATION CENTER — VTS POSITION
INDICATOR
1. Bow up
2. Bow down
NOTE: If the VTS UP or Down button
is pressed and held, the pump nozzle
will keep moving until the button is
released at the desired trim attitude
or the maximum trim position (up or
down) is reached.
Using Preset Trim Positions
Two preset trim positions can be se-
lected.
To select the highest trim position
recorded, double-click on the VTS UP
arrow button (bow up).
To select the lowest trim position
recorded, double-click on the VTS
DOWNarrowbutton(bowdown).
NOTE: If only one preset trim position
is recorded, double-click either UP or
DOWN arrow of the VTS button.
sdd2009-001-019_c
DOUBLE-CLICK UP OR DOWN TO USE
PRESET POSITIONS
1. Highest preset position on UP arrow
2. Lowest preset position on DOWN arrow
Recording Preset Trim Positions
Two different VTS trim positions may
be recorded for quickly selecting the
preferred watercraft trim attitude.
To record VTS preset trim positions:
1. Turn ON the electrical power by
pressing the START/STOP button
once.
2. Installing the tether cord on the en-
gine cut-off switch.
3. On the RH handlebar, press the
MODE button repeatedly until VTS
MODE is displayed.
_______________
99
