SUSPENSION
5. Press the SET button to display
DOCK MODE AUTO.
smo2009-002-114_dd
MODE ENTERED - DOCK MODE AUTO
6. Press the UP or DOWN arrow but-
tontotogglethedisplaytoDOCK
MODE OFF.
smo2009-002-114_ee
MODE DEACTIVATED - DOCK MODE OFF
7. Press the SET button, or wait for the
function to time out to save the set-
ting and return to main display.
You may now start the engine and
drive away using the selected DOCK
MODE.
CAUTION Operating the wa-
tercraft in DOCK MODE OFF pre-
vents the suspension from automat-
ically moving to the "down" position
when operating the watercr
aft at
slow speed or when stopping. This
maintains a higher center of gravity,
reduces stability, and m
akes the wa-
tercraft more prone to overturning.
aS (ajustableSuspension)
RXT-X aS
The adjustable Suspension (aS) al-
lowsthemovingdecktomoveinde-
pendently of the fixed deck, isolating
rider and passenger from the impact of
rough water.
With the aS feature, the moving deck
may be adjusted mechanically to ab-
sorb (dampen) water shocks according
to the driver riding style and water con-
ditions.
Spring Preload Adjustment
The spring preload can be easily ad-
justed using a 1/2" drive nut (adjuster).
The spring preload adjuster is located
under the seat.
RIDERS TOTAL
WEIGHT (KG/LB)
NBR OF
CLICKS ON
SPRING
ADJUSTER
(CLOCKWISE*)
57 kgf (125 lbf) 0
73 kgf (160 lbf) 2
89 kgf (195 lbf)
4
105 kgf (230 lbf) 6
120 kgf (265 lbf) 8
136 kgf (300 lbf) 10
152 kgf (335 lbf) 12
168 kgf (370 lbf)
14
184 kgf (405 lbf) 16
200 kgf (440 lbf) 18
* 0 is set at fully unscrewed position
(counterclockwise).
Damping Adjustment
The aS Suspension damping may be
personally adjustable according to the
driving preferences and water condi-
tions.
86
