EQUIPMENT
WARNING
Be aware of the iBR gate move-
ment when starting the engine,
shutting down the engine or using
the iBR lever. Automatic move-
ment of the gate may squeeze fin-
gers or toes of people taking a hold
on the back or your PWC.
8) Boarding Platform
A boarding platform covers the rear
deck area.
Two indentations in the platform are
used as foot rests for the rear facing
spotterwhentowingaskierortuber.
Twograbhandlesneartherearedgeof
the platform provide hand holds for a
person boarding from the water.
RXT-iS, GTX iS and GTX Limited iS
The platform also serves as a water-
tight cover for two rear storage bins
that are accessible when opening the
platform. It is hinged to the fixed deck
at the rear, and held closed by two
latches at its front corners.
To open the boarding platform, pull up
on each latch handle and lift the deck
fully up. A cylinder on the left side is
capable of holding the platform open.
smo2009-002-131_c
GTX LIMITED iS MODEL ILLUSTRATED
1. Boarding platform
2. Spotter foot rests
3. Grab handles
4. Latch handles
9) Speed-Ties
GTX Limited iS
Two speed-ties are provided for moor-
ing of the watercraft.
One speed-tie is located just below the
LH handlebar, the other is located in
the center rear edge of the boarding
platform.
smo2009-002-134_a
1. Front speed-tie
smo2009-002-131_d
1. Rear speed-tie
WARNING
– Do not use retractable ropes
when watercraft engine is run-
ning.
– Do not use to tow a watercraft.
Do not use to pull a person or
any object behind or to the side
of the watercraft.
– Do not use speed-tie rope as a
tie-down on a trailer.
_______________
75
