EQUIPMENT
smo2009-001-002
SKI/WAKEBOARD POST EXTENDED
To retract the post, push straight down
on the top of the post.
If the post becomes difficult to extend
or retract, simultaneously push in on
both sides of the locking clip toward
front of watercraft.
smo2009-001-003_a
PUSH TOWARD FRONT TO UNLOCK AND
REMOVE POST
1. Locking clip
WARNING
Make sure ski/wakeboard post is
fully extended and locked before
use. Completely retract and lock
when not used. Use caution with
skier/wakeboarder in tow as tow
rope may backlash to watercraft
when released. Never perform a
sharp turn when towing a skier,
wakeboarder or any toy.
NOTICE
The ski/wakeboard post is
designed for towing a skier or wake-
boarder with a maximum gross
weight of 114 kg (250 lb).
Always have one person other than the
operator as an observer.
NOTE: The handles on the ski/wake-
board post are provided as a handhold
for the observer.
NOTICE
Never use the ski/
wakeboard post to tow other water-
crafts. Respect the maximum load
limit rating of the ski/wakeboard
post. Overloading can affect ma-
neuverability, stability and perfor-
mance.
14) Wakeboard Rack
WAKE Pro Model
A convenient removable rack to carry a
wakeboard on the watercraft when on
the water.
NOTE: The wakeboard rack can be in-
stalledon the LH sideofthe watercraft.
To install:
1. Insert the hooks on the lower por-
tion of the rack into the lower retain-
ing bracket located on the hull under
the LH side bumper.
smo2010-002-007_a
RETAINING BRACKETS FOR WAKEBOARD
RACK
1. Lower retaining bracket
2. Upper retaining bracket
_______________
79
