MAINTENANCE PROCEDURES
NOTE: The watercraft is level when
it is in water. When on a trailer, raise
trailer tow pole and block in this posi-
tion when bumper rail is level.
Add coolant/demineralized water to
adjust coolant level between marks
as required. Use a funnel to avoid
spillage. Do not overfill.
Properly reinstall and tighten filler cap,
then reinstall ventilation box and close
seat.
NOTE: A cooling system that fre-
quently requires coolant is an indica-
tion of leaks or engine problems. See
an authorized Sea-Doo dealer.
Engine Coolant Replacement
Coolant replacement should be per-
formed by an authorized Sea-Doo
dealer.
Ignition Coils
Ignition Coil Access
RXT iS, GTX iS, GTX Limited iS
Open seat.
Remove rear air ventilation box.
Models other than iS
Open seat.
Remove engine cover.
Ignition Coil Removal
Disconnect ignition coil connector.
smr2009-032-004_b
1. Ignition coil
2. Ignition coil connector
NOTICE
Do not remove the igni-
tion coil before disconnecting the
input connector or the wires may be
damaged. Do notpryup ignition coil
with a screwdriver to avoid damage.
NOTE: Twist ignition coil in both direc-
tions as you pull it up to ease removal.
Remove ignition coil from spark plug.
Ignition Coil Installation
1. Pull rubber seal down.
sbs2009-011-002_a
1. Rubber seal pulled down
2. Apply DOW CORNING 111 (P/N 413
707 000) to rubber seal seat as
shown.
smr05-015-002_d
1. Apply product here
______________
133
