BREAK-IN INSPECTION
REPLACE
ADJUST
LUBRICATE
CLEAN
BREAK-IN INSPECTION CHART
INSPECT
STEERING SYSTEM
Steering cable and connections X
Steering nozzle bushings X
O.T.A.S. X
PROPULSION SYSTEM
Carbon ring and rubber boot (drive shaft) X
Impeller boot X
Sacrificial anode (if so equipped) X
Impeller and impeller wear ring clearance X
Pump mounts X
iBR SYSTEM (intelligent Brake and Reverse)
iBR gate backlash X
iBR support plates X
iBR friction sleeves X
iBR connecting arms, sleeves and bushings X
iBR U lever, VTS trim ring, iBR gate and bushings X
iBR locking sleeve X
iBR protective guard X
iS SYSTEM (intelligent Suspension)
iS oil X
iS position sensor X
aS SYSTEM (adjustable Suspension)
Nitrogen remote reservoir (adjustment knob, mounts) X
HULL/BODY
Hull X
Ride plate and water intake grate X
126
