C) R
ELEVELLING ZONE ADJUSTMENT FOR HYDRAULIC LIFTS
HIGHLIGHT: Relevelling Zone
The Relevelling Zone is the space of misalignment between the car and the floor
without the car relevels. When the car exceeds this space the relevelling control
starts.
4. Move the sensor IS toward the centre of a length equal to the space of relevelling
zone required.
5. Gradually increase the value of timer 4.12 so that, when upward runs are repeated,
the car stops aligned with the floor sill.
The timer value depends on the required speed and Relevelling Zone.
6. Move the sensor ID toward the centre so that, in coming down to the landing, the car
stops aligned with the sill.
WARNING
The relevelling control with open doors is permitted by the safety circuit (CS1
device and C, D sensors).
When the led C and D of the CS1 device are on, the relevelling control is
permitted; if one or both of the leds are off the relevelling control with open doors
is interrupted.
