© 2014 SeaStar Solutions Optimus Installation Manual, Rev. E
1-5
Steering Service
Valve Labels
SmartCylinder Labels
Figure 1-4. SmartCylinder labels.
WARNING WARNING
682012
Avoid steering failure: Turn
coupling clockwise to lock
(click). Do not overtighten.
Avoid steering failure: Turn
coupling clockwise to lock
(click). Do not overtighten.
To be installed close to the service valve.
Figure 1-5. Steering service valve labels.
