SeaSTAR OPTIMUM EPS - Cantrak Display

© 2014 SeaStar Solutions Optimus Installation Manual, Rev. E
4-5
All CANtrak Displays are identical and can be used at any station.
The display must be easily visible from the helm station. The display
may be located in any position, however it is strongly suggested that,
if it is exposed to the weather, it should be on a sloped surface so
water does not lay on the screen.
For mounting templates, please see Appendix A.
4.3.2 CANtrak Display
Part No. ED1700
A CANtrak display is required at the main helm station, but is optional
at secondary control station(s).
Figure 4-4.
NOTICE
DO
DO NOT
Mount vertical to hull or wall Mount at an angle less than 60°
Mount parallel to
boat deck
<60°<60°
