SeaSTAR OPTIMUM EPS - PCM Mounting Considerations

© 2014 SeaStar Solutions Optimus Installation Manual, Rev. E
5-8
• MountthePCMtoaat,verticalsurfaceparalleltothewallor
hull. It may be mounted no more than 15 degrees from vertical.
• ThePCMmustbemountedinacool,drylocation.
• Anyunusedconnectorsmusthaveasealingpluginstalled.
5.3.2 PCM Mounting Considerations
Figure 5-8.
DO
DO NOT
Mount parallel to
boat deck
Mount vertical (parallel) to hull or wall, plus or minus 15°
15°
Expose to vibration, shocks or
excessive heat
Protect from sun
and elements
