SeaSTAR OPTIMUM EPS - Networks and Wiring; Network Diagrams

© 2014 SeaStar Solutions Optimus Installation Manual, Rev. E
6-1
Figure 6-2. Network diagram — dual station, multi-engine.
Figure 6-1. Network diagram — single station, multi-engine.
6.0 NETWORKS AND WIRING
The following schematics illustrate the CAN1 and CAN2 network
connections for single and dual station installations. Connections are
made with simple harness connections, as shown in section 6.2.
6.1 Network Diagrams
COLOR
CANtrak 1
HELM
1
CERTIFIED
AUTOPILOT
(Optional)
PCM
OPTIMUS CAN2
OPTIMUS CAN1
IGNITION
CM204XX
CM204XX
CM21504
CM20304
CM100XX CM100XX
PURPLE x 2
TERMINATOR
CM10051
IGNITION
SOURCE
TEE
CM10060
BUZZER
COLOR
CANtrak 2
HELM
2
CM21504
BUZZER
TERMINATOR
CM10052
COLOR
CANtrak 1
HELM
1
CERTIFIED
AUTOPILOT
(Optional)
PCM
OPTIMUS CAN2
OPTIMUS CAN1
IGNITION
CM204XX
CM21504
CM20304
CM100XX
PURPLE x 2
TERMINATOR
CM10051
IGNITION
SOURCE
TEE
CM10060
BUZZER
TERMINATOR
CM10052
