SeaSTAR OPTIMUM EPS - Page 36

© 2014 SeaStar Solutions Optimus Installation Manual, Rev. E
4-14
BLACK ANODIZED: HO82XX
POLISHED STAINLESS STEEL: HO87XX
PIGTAIL FITTINGBULKHEAD
Bulkhead Hoses
DO NOT INSTALL BULKHEAD HOSES BELOW THE WATERLINE.
Figure 4-12. Single bulkhead plate.
POLISHED STAINLESS
STEEL ONLY
Figure 4-13. Dual bulkhead plate.
WARNING
