© 2014 SeaStar Solutions Optimus Installation Manual, Rev. E
5-23
FAILURE TO PROPERLY TIGHTEN THE LOCKNUT
MAY LEAD TO LOSS
OF STEERING CONTROL. LOSS OF STEERING CONTROL MAY RESULT
IN UNPREDICTABLE BOAT BEHAVIOR, COLLISION WITH AN OBSTACLE
AND/OR EJECTION FROM VESSEL, LEADING TO PROPERTY DAMAGE,
PERSONAL INJURY AND/OR DEATH.
Figure 5-23. Re-orientable hose fitting.
Figure 5-24.
WARNING
Due to material variability, fitting installation torque differs between
the power steering pump and the steering cylinder. Be sure to use
the correct installation torque to avoid irreparable damage to the
pump housing or cylinder body when installing an ORB fitting.
NOTICE
