1 - 87
(6) Parameters
Refer to 17-2 Safety Guard (Comparison).
(7) Alarms
No. 213 Safety guard tool length operation error
[#001]
TOOL LENGTH button has been pushed except in reset state.
[#002] After tool length measurement is started, prior to resetting (M02, M30, Reset
key, %) being applied, TOOL LENGTH button is set OFF.
[#003] Measurement has taken place for 2 or more axes simultaneously.
[#004] On start of tool length measurement for 5-sided machine, a horizontal shaft
head is fitted. Or, a horizontal shaft head is fitted while in measurement.
[#005] Either the manual or the handle mode switch has been pressed.
No. 715 Measurement error Used in machine-lock state.
(8) Cautions
[1] Operate tool length measurement with the SINGLE BLOCK switch turned OFF.
[2] When using tool offset or multiple corrections using a tool number, the tool length is
measured per correction number.
[3] Perform operation with machine-lock OFF state.
[4] Perform tool length measurement as holding Auto mode.
[5] As ATC canned cycle is operated in M06, set the parameter for ATC canned cycle
beforehand.
