1 - 91
#3 = 0 M00, M01 is executed on tool length execution.
1 M00, M01 is ignored on tool length execution.
No. 6251 Distance from the reference point to the reference gauge Z end face.
No. 6255 Distance from the spindle nose to the -Z directional end face of the
probe sphere.
No. 6256 Retouch return amount
No. 6258 Reference gauge position (X axis)
No. 6259 Reference gauge position (Z axis)
(5) Alarms
No. 214 Safety guard verification operation error
[#001]
COLLATION button has been pushed ON except in reset state.
[#002] After verification is started, prior to resetting (M02, M30, Reset key, %) being
applied, COLLATION button has been set OFF.
[#003] Measurement has been performed for 2 or more axes simultaneously.
[#004] On start of verification measurement for 5-sided machine, a horizontal shaft
head is fitted. Or, in measurement, a horizontal shaft head is fitted.
[#005] Manual or Handle mode switch has been pushed.
No. 215 Safety guard verification error ....... Tool has entered disabled area in the
safety guard verification.
No. 715 Measurement error ........................ Used in machine-locked state.
(6) Cautions
[1] Operate safety guard comparison with the SINGLE BLOCK switch turned off.
[2] Be sure to perform zero point return after operating safety guard comparison.
[3] Perform operation with machine-lock OFF.
[4] Perform verification as holding Auto mode.
